Samlongda PVC layflat hose Size: 3/4" - 12"
Samlongda New layflat hose made from extruded high quality PVC resin with excellent wear & tear properties. The reinforcement is from high tensile filament polyester yarn. The "extrusion through the weave" production method of layflat hose gives a very strong bonding between cover and lining as well as firmly encapsulating the woven polyester.
(1) Light weight, good flexibility, bright color, smooth smearing layer on our new layflat hose
.
(2) Flat roll and easy for take back, convenient for moving and non limitation for length.
(3) Capable for keeping the flexibility and elasticity under the low-temperature water.
(4) Anti-hi pressure, corrosion resistance and ageing resistance. Heave duty layflat hose could reach 11bar working pressure.
(5) Applied to the lines of the auxiliaries for agricultural tools against the drought, project, miming, environment protection, industry and so on.
Samlongda New layflat hose made from extruded high quality PVC resin with excellent wear & tear properties. The reinforcement is from high tensile filament polyester yarn. The "extrusion through the weave" production method of layflat hose gives a very strong bonding between cover and lining as well as firmly encapsulating the woven polyester.
(1) Light weight, good flexibility, bright color, smooth smearing layer on our new layflat hose
.
(2) Flat roll and easy for take back, convenient for moving and non limitation for length.
(3) Capable for keeping the flexibility and elasticity under the low-temperature water.
(4) Anti-hi pressure, corrosion resistance and ageing resistance. Heave duty layflat hose could reach 11bar working pressure.
(5) Applied to the lines of the auxiliaries for agricultural tools against the drought, project, miming, environment protection, industry and so on.
| Model | Size | Thickness | Weight | W.P. | B.P. | |
| Inch | mm | mm | g/m | bar | bar | |
| Economic duty layflat | 1" | 26 | 1.3 | 150 | 4 | 12 |
| 1-1/4" | 33 | 1.2 | 170 | 4 | 12 | |
| 1-1/2" | 41 | 1.25 | 205 | 5 | 15 | |
| 2" | 53 | 1 | 230 | 4 | 12 | |
| 2.5" | 66 | 1.15 | 320 | 4 | 12 | |
| 3" | 78 | 1.1 | 360 | 4 | 12 | |
| 4" | 104 | 1.3 | 550 | 4 | 12 | |
| 5" | 128 | 1.35 | 750 | 4 | 12 | |
| 6" | 155 | 1.4 | 900 | 4 | 12 | |
| 8" | 202 | 2 | 1785 | 3 | 9 | |
| 10" | 250 | 2.65 | 2650 | 2.5 | 7.5 | |
| 12" | 302 | 2.55 | 3100 | 2 | 6 | |
| Size | Thickness | Weight | W.P. | B.P. | ||
| Inch | mm | mm | g/m | bar | bar | |
| Medium Duty layflat | 3/4" | 20 | 1.35 | 112 | 7 | 21 |
| 1" | 26 | 1.4 | 165 | 7 | 21 | |
| 1-1/4" | 33 | 1.3 | 190 | 7 | 21 | |
| 1-1/2" | 41 | 1.3 | 230 | 7 | 21 | |
| 2" | 53 | 1.3 | 300 | 6 | 18 | |
| 2.5" | 66 | 1.7 | 430 | 7 | 21 | |
| 3" | 78 | 1.45 | 500 | 6 | 18 | |
| 4" | 104 | 2.3 | 865 | 6 | 18 | |
| 5" | 128 | 2.3 | 1080 | 6 | 18 | |
| 6" | 155 | 2.4 | 1600 | 6 | 18 | |
| 8" | 202 | 2.65 | 2020 | 4 | 12 | |
| Size | Thickness | Weight | W.P. | B.P. | ||
| Inch | mm | mm | g/m | bar | bar | |
| Heavy Duty layflat | 3/4" | 20 | 1.55 | 140 | 10.5 | 31.5 |
| 1" | 26 | 1.7 | 200 | 10.5 | 31.5 | |
| 1-1/4" | 33 | 1.45 | 210 | 10.5 | 31.5 | |
| 1-1/2" | 41 | 1.9 | 290 | 10.5 | 31.5 | |
| 1-3/4" | 45 | 1.6 | 320 | 8 | 24 | |
| 1-3/4" | 45 | 2 | 350 | 10.5 | 31.5 | |
| 2" | 53 | 1.5 | 350 | 8 | 24 | |
| 2" | 53 | 2.05 | 420 | 10.5 | 31.5 | |
| 2.5" | 66 | 2.2 | 650 | 10.5 | 31.5 | |
| 3" | 78 | 2.5 | 850 | 10 | 30 | |
| 4" | 104 | 2.5 | 1000 | 9 | 27 | |
| 5" | 127 | 3.1 | 1800 | 8 | 24 | |
| 6" | 155 | 3.3 | 2000 | 8 | 24 | |
| 8" | 202 | 2.95 | 2200 | 5 | 15 | |
| 8" | 202 | 3.15 | 2800 | 6 | 18 | |
| PS: Other weight could be customized | ||||||
