Products Description:
1.Size:6.5/8.0/10/13/16/25mm
2.W.P:20/30Bar
3.B.P:70/120Bar
4.Thickness:3mm
5.Color:Yellow,Red color etc.
6.Working Temperature:-10ºC to 70ºC
7.Package:50/100M/Roll
Products Features:
1.Made with high-qualtiy PVC and strong reinforced yarn
2. Strong peeling adhesion between yarn and inner-outer tube
3. Stable against kinking and twisting under work pressure
4. High resistance to corrosion,aging
5. Air compressor,automated air line,Rock drill,Cleaning equipment,Air Supply,Construction equipment.
Package Details:
Packaged: 100Meters/Roll,1Roll/CTN
Carton dimensions:45*14*45cm
N.W:12KGS G.W:14KGS
980CNTS/20GP Container
1970CNTS/40GP Container
2400CNTS/40HQ Container
Delivery Details:
20-25 days after receive the deposite
| ITEM NAME | CODE NO. | I.D.(mm) | W.P.(BAR) | B.P.(BAR) |
| 1PLY-3LAYER | SA65 | 6.5 | 20 | 70 |
| SA80 | 8 | 20 | 70 | |
| SA95 | 9.5 | 20 | 60 | |
| SA13 | 13 | 20 | 60 | |
| SA16 | 16 | 15 | 50 | |
| SA19 | 19 | 15 | 50 | |
| SA25 | 25 | 15 | 40 | |
| WEAVE REINFORCED | SAB65 | 6.5 | 30 | 120 |
| SAB80 | 8 | 30 | 120 | |
| SAB95 | 9.5 | 30 | 120 | |
| SAB13 | 13 | 30 | 120 | |
| SAB16 | 16 | 30 | 120 | |
| SAB19 | 19 | 30 | 100 | |
| SAB25 | 25 | 30 | 100 |
